Hyundai Tucson (NX4) 2022-2025 Service Manual: PTG Spindle
- Removal
1.Disconnect the negative (-) battery terminal.
2.Remove the rear pillar trim.(Refer to Body (Interior and Exterior) - Interior Trim - Rear Pillar Trim)
3.Disconnect the PTG spindle connector (A).
4.Using a flat-tip screwdriver, remove the mounting clip (A).
5.Remove the spind ...
Hyundai Tucson (NX4) 2022-2025 Service Manual: Components and Components Location
- Components
1. Camshaft bearing cap2. Exhaust camshaft3. Exhaust CVVT assembly4. Intake camshaft5. Intake E-CVVT assembly6. Cam carrier7. Cylinder head8. Swing arm9. Hydraulic Lash Adjuster (HLA)10. Cylinder head gasket11. Retainer lock12. Retainer13. Valve spring14. Valve stem seal15. Exhaus ...
